Turtle Safe Lighting Fixtures
DMP Wildlife Certified Lighting
Wall Sconce
The DMP Family of LED luminaires is available in two configurations, in two wattages, with an IES Type V distribution. They are designed to replace traditional exterior lighting systems up to 100w. Typical applications include wall sconce and small walkway canopy lights. In the in the “H” specification, it may also be used to replace up to 175W MH or HPS fixtures for parking garages and entranceways. The DMP Series has been specifically designed to meet or exceed the stringent Florida Fish & Wildlife requirements for exterior wildlife-friendly lighting requiring monochromatic Amber-Orange or Red lights. Bespoke Nichia or Cree LEDs operate between 585 and 625 nm, greater than 560nm required for wildlife protection. Typical applications include balconies, covered exterior walkways, stairwells, and alcove lighting. The DMP-01 is designed for replacement of balcony wall sconces, the DMP-02 variant is designed to be surface mounted at heights up to 12’ for exterior walkway lighting. Mounting heights of 6 to 14 feet can be used based on light level and uniformity requirements.
HOUSING
Low Profile T-6061 Aluminum Housing, Full shielding provided as
standard on all units to provide maximum compliance with
applicable regulations.
LENS
Molded UV-Resistant Acrylic Optical Lens Designed for optimum downward light dispersion while meeting or exceeding dark sky
requirements.
MOUNTING OPTIONS
Included Easy-mount Bracket Fits Standard 4” Electrical Box,
Allowing One-Person Installation. Optional Mounts Available.
DRIVER AND LED
U.L. Listed Universal voltage 120-277V standard dimmable driver,
Proprietary design SinkPAD™ Nichia® or CREE Amber LED
boards DMP-01V 8W (System 9.5W), DMP-01VH 16w (System
19W) All components are field serviceable and carry a ten (10) year
warranty.
LISTINGS AND RATINGS
All electrical components are U.L. listed or recognized CSA listed for wet locations, ANSI/UL 1598, 8750 (damp locations when used with LVN), IP65 sealed LED compartment, U.S.A. Buy American Act compliant.
Wall Sconce
Dimensions
Height: 11”
Width: 4”
Depth: 4”
Fixed Shield: 5.5
Garage & Site Lighter
The DMP Family of LED luminaires is available in two configurations, in two wattages, with an IES Type V distribution. They are designed to replace traditional exterior lighting systems up to 100w. Typical applications include wall sconce and small walkway canopy lights. In the in the “H” specification, it may also be used to replace up to 175W MH or HPS fixtures for parking garages and entranceways. The DMP Series has been specifically designed to meet or exceed the stringent Florida Fish & Wildlife requirements for exterior wildlife-friendly lighting requiring monochromatic Amber-Orange or Red lights. Bespoke Nichia or Cree
LEDs operate between 585 and 625 nm, greater than 560nm required for wildlife protection. Typical applications include balconies, covered exterior walkways, stairwells, and alcove lighting. Mounting heights of 8 to 20 feet can be used based on light level and uniformity requirements. The DMP- 03 is specifically designed for parking garages and exterior pole lighting.
HOUSING
Low Profile T-6061 Aluminum Housing, Full shielding provided as
standard on all units to provide maximum compliance with applicable regulations.
LENS
Molded UV-Resistant Acrylic Optical Lens Designed for optimum downward light dispersion while meeting or exceeding dark sky requirements.
MOUNTING OPTIONS
Included Easy-mount Bracket Fits Standard 4” Electrical Box, Allowing One-Person Installation. Optional Mounts Available.
DRIVER AND LED
U.L. Listed Universal voltage 120-277V standard dimmable driver,
Proprietary design SinkPAD™ Nichia® or CREE Amber LED boards
DMP-03 36W (System 40W), DMP-03 76w (System 80W)
All components are field serviceable and carry a ten (10) year warranty.
LISTINGS AND RATINGS
All electrical components are U.L. listed or recognized CSA listed for wet locations, ANSI/UL 1598, 8750 (damp locations when used with LVN), IP65 sealed LED compartment, U.S.A. Buy American Act compliant.
Garage & Site Lighter
Dimensions
Height: 12”
Width: 12”
Depth: 8”
Fixed Shield: 6”
Walkway Ceiling Mount
The DMP Family of LED luminaires is available in two configurations, in two wattages, with an IES Type V distribution. They are designed to replace traditional exterior lighting systems up to 100w. Typical applications include wall sconce and small walkway canopy lights. In the in the “H” specification, it may also be used to replace up to 175W MH or HPS fixtures for parking garages and entranceways. The DMP Series has been specifically designed to meet or exceed the stringent Florida Fish & Wildlife requirements for exterior wildlife-friendly lighting requiring monochromatic Amber-Orange or Red lights. Bespoke Nichia or Cree LEDs operate between 585 and 625 nm, greater than 560nm required for
wildlife protection. Typical applications include balconies, covered
exterior walkways, stairwells, and alcove lighting. The DMP-01 is
designed for replacement of balcony wall sconces, the DMP-02 variant is designed to be surface mounted at heights up to 12’ for exterior walkway lighting. Mounting heights of 6 to 14 feet can be used based on light level and uniformity requirements.
HOUSING
Low Profile T-6061 Aluminum Housing, Full shielding provided as
standard on all units to provide maximum compliance with
applicable regulations.
LENS
Molded UV-Resistant Acrylic Optical Lens Designed for optimum downward light dispersion while meeting or exceeding dark sky
requirements.
MOUNTING OPTIONS
Included Easy-mount Bracket Fits Standard 4” Electrical Box,
Allowing One-Person Installation. Optional Mounts Available.
DRIVER AND LED
U.L. Listed Universal voltage 120-277V standard dimmable driver,
Proprietary design SinkPAD™ Nichia® or CREE Amber LED
boards DMP-01V 8W (System 9.5W), DMP-01VH 16w (System
19W) All components are field serviceable and carry a ten (10) year
warranty.
LISTINGS AND RATINGS
All electrical components are U.L. listed or recognized CSA listed for wet locations, ANSI/UL 1598, 8750 (damp locations when used with LVN), IP65 sealed LED compartment, U.S.A. Buy American Act compliant.
Walkway Ceiling Mount
Dimensions
Height: 8”
Width: 6”
Depth: 6”
Fixed Shield: 5.5”
